卧式储罐参数
|
公称容器
m3
|
计算容器
m3
|
主要容器
|
罐体厚度
|
重量kg
|
|||||
|
Dg
|
L1
|
L2
|
a
|
b
|
C
|
||||
|
3
|
2．93
|
1000
|
3900
|
3400
|
500
|
25
|
50
|
12
|
297
|
|
4
|
4，07
|
1200
|
3800
|
3200
|
500
|
25
|
80
|
15
|
480
|
|
5
|
5．03
|
1400
|
3700
|
2800
|
500
|
25
|
80
|
18
|
650
|
|
6
|
6．3
|
1600
|
3400
|
2600
|
500
|
25
|
80
|
18
|
750
|
|
8
|
8．64
|
1800
|
3700
|
2800
|
500
|
25
|
80
|
20
|
840
|
|
10
|
10．17
|
1800
|
4300
|
3400
|
500
|
40
|
80
|
20
|
1060
|
|
16
|
15．17
|
1800
|
6500
|
5600
|
500
|
40
|
80
|
20
|
1500
|
|
20
|
20．26
|
2200
|
5700
|
4600
|
500
|
50
|
100
|
25
|
2273
|
|
25
|
24．83
|
2200
|
6900
|
5800
|
500
|
50
|
100
|
30
|
2718
|
|
30
|
32
|
2600
|
6800
|
5600
|
500
|
50
|
100
|
32
|
4132
|
|
40
|
40
|
2300
|
7900
|
6700
|
500
|
50
|
100
|
35
|
5086
|
|
50
|
50．06
|
2800
|
8600
|
7200
|
500
|
50
|
100
|
40
|
6727
|
|
63
|
60．6
|
2800
|
10800
|
9400
|
500
|
50
|
100
|
45
|
8797
|
|
70
|
71．36
|
3000
|
10500
|
9000
|
500
|
50
|
100
|
48
|
10012
|
|
80
|
80
|
3000
|
11720
|
10220
|
600
|
50
|
100
|
50
|
11463
|
|
100
|
99．96
|
3000
|
14550
|
13050
|
600
|
50
|
100
|
50
|
13863
|
|
120
|
120．1
|
3200
|
15400
|
73820
|
600
|
50
|
100
|
55
|
16971
|
